Industrial camera monocular lens with 0.1-1.3x magnification for detailed inspection work

This industrial monocular lens serves inspection and quality control applications requiring detailed visual analysis of components. With adjustable magnification from 0.1x to 1.3x, it provides approximately 10-130x magnification on connected displays, enabling operators to examine small parts, assemblies, and surface features that might be difficult to assess with standard vision systems. The lens accommodates various industrial camera formats while maintaining consistent optical performance across its magnification range.

Technical Specifications and Performance

The lens delivers measurable technical parameters designed for industrial inspection environments where precise visual assessment supports quality decisions.

Magnification and Scaling

Offering 0.1x to 1.3x magnification, this lens translates to approximately 10-130x magnification on typical industrial displays. This range accommodates everything from overview inspection to detailed feature examination. The 1:11 scaling ratio provides proportional measurement capability, allowing operators to gauge component dimensions directly through the visual system without requiring separate measurement tools.

Working Distance Flexibility

With a working distance range of 60mm to 300mm, the lens accommodates various installation configurations and subject positioning requirements. This flexibility allows integration into existing production lines where camera-to-subject distance may be constrained by machinery or workspace limitations. The extended range also supports inspection of components that cannot be positioned at fixed distances due to their size or handling requirements.

Field of View Adjustments

The field of view adjusts from 8mm×4.5mm at maximum magnification to 40mm×33mm at minimum magnification. This variability enables operators to balance detail level with inspection area coverage, selecting narrower views for intricate component features or wider views for assembly verification. The rectangular field accommodates typical component shapes encountered in manufacturing environments.

Physical Characteristics and Integration

Designed for practical integration into industrial vision systems, the lens features compact dimensions suited to various mounting arrangements.

Size and Mounting Compatibility

Measuring 30mm in diameter and 84mm in length, the lens fits standard industrial camera housings and mounting systems. The black finish reduces light reflection that could interfere with inspection accuracy. These dimensions support installation in space-constrained locations while maintaining the optical path length needed for the specified magnification performance.

Industrial Environment Suitability

The metal housing provides structural integrity in manufacturing environments where equipment may experience vibration or incidental contact. While specific environmental ratings aren't provided, the construction suggests suitability for typical indoor industrial settings rather than harsh outdoor or wet conditions. The optical elements require standard protection from excessive dust accumulation that could degrade image quality.

Application Scenarios and Practical Benefits

This lens addresses specific industrial inspection challenges where visual assessment supports quality control, assembly verification, and defect identification.

Component Inspection and Quality Control

The magnification range supports inspection of electronic components, mechanical parts, and small assemblies where surface defects, dimensional accuracy, or assembly completeness must be verified. The adjustable working distance accommodates parts of varying sizes presented at different distances from the camera, while the scaling ratio enables direct measurement through the visual system.

Production Line Integration

With its compact dimensions and flexible working distance, the lens integrates into existing production line vision systems without requiring extensive reconfiguration. The black finish minimizes reflections that could interfere with accurate image capture, particularly important when inspecting shiny or reflective materials common in manufacturing environments.

Why This Lens Supports Inspection Work

The combination of adjustable magnification, flexible working distance, and compact dimensions makes this lens suitable for various industrial inspection scenarios. It provides the optical parameters needed for detailed visual assessment without requiring multiple specialized lenses for different magnification requirements. The 1:11 scaling ratio adds practical measurement capability beyond simple visual inspection.
